Boeing
B367-80
#

Photo: Robert Deering 10/23/2006
Smithsonian National Air and Space Museum
Dulles International Airport (IAD)

Chantilly, Virginia

The Boeing 367-80, known simply as the Dash 80, is an American quadjet prototype built by Boeing to demonstrate the advantages of jet propulsion for commercial aviation. It served as basis for the design of the KC-135 tanker and the 707 airliner.

The Dash 80 first flew in 1954, less than two years from project launch. Its US$16 million cost (equivalent to $152 million today) was an enormous risk for Boeing, which at the time had no committed customers. Only one example was built, which has been preserved and is currently on public display at the Udvar-Hazy Center in Virginia.

Design and Developement

By the late 1940s two developments encouraged Boeing to begin considering building a passenger jet. In 1950 Boeing tentatively produced a specification for a jet airliner dubbed the Model 473-60C. The airlines were unconvinced because they had no experience with jet transports and were enjoying success with piston engined aircraft such as the Douglas DC-4DC-6Boeing Stratocruiser and Lockheed Constellation.

Boeing was experienced at selling to the military but had not enjoyed the same success with civil airliners. This market was dominated by Douglas which was adept at meeting the needs of airlines by refining and developing its range of propeller-driven aircraft, and in 1950 was marketing the forthcoming DC-7. Boeing decided the only way to overcome the airlines' suspicion of the jet – and of itself – was to show them a completed aircraft.

Boeing had studied developments of its existing Model 367 (the KC-97 Stratofreighter) incorporating swept wings and podded engines; and chose to build the 367-80, which retained little of the KC-97 except the upper fuselage diameter (and the possibility of building some of the fuselage with existing tooling). Although the design was announced publicly as the Model 707, the prototype was referred to within Boeing simply as the Dash 80 or "-80

The Dash 80 fuselage was wide enough at 132 inches (335 cm) for five-abreast seating; two on one side of the aisle and three on the other. The fuselage diameter for the production KC-135 was widened to 144 inches (366 cm) and Boeing originally hoped to build the 707 fuselage with that width. By the time the Boeing company committed to production, the decision had been made to design the production model 707 as a six-abreast design, with a larger 148-inch-diameter (376 cm) fuselage, after C. R. Smith, CEO of American Airlines, told Boeing he wouldn't buy the 707 unless it was an inch wider than the then-proposed Douglas DC-8 passenger jet. This decision did not unduly delay the introduction of the production model since the -80 had been largely hand-built, using little production tooling.

Operational History

By early 1952 the designs were complete and in April the Boeing board approved the program. Construction of the Dash 80 started in November in a walled-off section of Boeing's Renton plant. As a proof of concept prototype there was no certification and no production line and most of the parts were custom built. The aircraft was not fitted with an airline cabin; a plywood lining housed the instrumentation for the flight test program.

Boeing used the Dash 80 on demonstration flights for airline executives and other industry figures. These focused attention on the question of what the cabin of a passenger jet should look like. In a departure from its usual practice Boeing hired industrial design firm Walter Dorwin Teague to create a cabin as radical as the aircraft itself.

Prior to demonstration for passenger airlines, the Dash 80 was fitted with Boeing's Flying Boom for aerial refueling which served as a prototype for the KC-135 Stratotanker and its later derivatives.

Use As An Experimental Aircraft

After the arrival of the first production 707 in 1957 the Dash 80 was adapted into a general experimental aircraft and used by Boeing to test a variety of new technologies and systems. One of its most important tasks during the late 1950s was to test systems for the new Boeing 727, including the fitting of a fifth engine in the rear fuselage. Other tests included experiments with different airfoil shapes and a number of high lift devices such as blown flaps, in which compressed air bled from the engines is directed over the flaps to increase lift during takeoff and landing.

Final Flight

After 2,350 hours and 1,691 flights the aircraft was withdrawn from use in 1969 and placed in storage. On May 26, 1972 Boeing donated the 367-80 to the Smithsonian Air and Space Museum, which had designated it one of the 12 most significant aircraft of all time. For the next 18 years the aircraft was stored at a "desert boneyard" now called the 309th Aerospace Maintenance and Regeneration Group (AMARG) at Davis-Monthan Air Force Base near TucsonArizona before being retrieved by Boeing in 1990 for restoration. The Dash 80's final flight was to Dulles International Airport near Washington, D.C. on August 27, 2003. Repainted to its original yellow and brown Boeing livery, it was put on display at the Steven F. Udvar-Hazy Center, an annex of the Smithsonian Institution's National Air and Space Museum, located adjacent to Dulles Airport in Chantilly, Virginia.

Source: Wikipedia
